ASC Presents its New Tilt Sensor in Four Different Configurations

ASC, the leading manufacturer of accelerometers, angular rate sensors and IMUs (inertial measurement units), has now unveiled its first tilt sensor and included it in its product range.

The ASC TS91V1-090 is a uniaxial sensor in an aluminium housing, with stand-out features including its high resolution (0.005º) and operability over a wide temperature range. This means it is perfectly suited for measuring angles in construction, the agricultural sector and that of renewable energies as well as in rail and automotive sectors.

Tilt Sensor for Rail
ASC TS91V1-090 Tilt Sensor

ASC TS91V1-090 Tilt Sensor

The ASC TS91V1-090 tilt sensor, which leverages MEMS technology, is available as both a uniaxial and biaxial configuration, and measures statically from +/- 90 degrees. The sensor is available in aluminium housing with protection class IP67 or in a stainless steel housing and protection class IP68 when more demanding usage requirements are imposed, for which hermetic tightness must be guaranteed. The ASC tilt sensor can measure in both horizontal and vertical directions.

Related Post:  Position Sensing of Mechanical Components in Rail Increases Safety

The new ASC TS91V1-090 includes both a high shock limit of 5000g and an effective temperature coefficient from the offset of 0.02/ºC. The sensor also boasts a long-term offset stability of 0.1° per year and can be used within a temperature range of -40 to +120°C. The TS91V1-090 and its differential analogue output can be supplied with voltage ranging from 6 to 36 VDC. The ASC TS91V1-090 is supplied either factory-calibrated or, upon customer request, with DAkkS calibration.


The sensor measures tilts and is mainly used for the purpose of preventing accidents as well as for monitoring systems. For example, it supports the task of systematically monitoring cranes to prevent any tilt or inclination. Meanwhile, within solar fields, the sensor can be used to determine the right angle at which to align the solar module with the sun. The new ASC sensor also has scope to control the tilting of bridges. Plus, it also functions to control the horizontal and vertical positional determination of ships and their cargo. In the vehicle and rail sectors, the sensor is used for wheel alignment and track alignment respectively. Construction is another possible area of use. In this respect, and with operational safety in mind, the tilting of vehicles while in operation is monitored, for example diggers, tipper vehicles and working platforms.

Related Post:  Ruggedized M12 Industrial Ethernet Switches for Rail Vehicles and Busses

Renate Bay, Managing Associate at ASC, said:

“We are more than happy that the ASC TS91V1-090 has allowed us to add a further top-quality sensor to our product range. The tilt sensor has wide-ranging applications and paves the way for our customers to monitor their machinery and equipment reliably. Depending on the requirement, we offer the sensor in a range of configurations”

ASC Sensors

ASC prioritises the task of developing bespoke solutions and thus adapts the sensor plugs and cables to their respective requirements. This means customers have access to the full range of service features including maintenance, repair and calibration.

Original article © ASC.
