Connection Module VM 8-8 Cat.7A Assembly

Contact: Contact supplier View: View supplier

The Telegärtner VM 8-8 modules are employed as connections and extensions of commercially available, shielded and unshielded twisted-pair installation cables (Cat.5e/ Cat.6/Cat.6A/Cat.7/Cat.7A) in the following applications: transition point/consolidation point, cable extensions, damaged cables, cable rerouting.

When VM 8-8 modules are used, the cable segments in a structured wiring system do not need to be laid out again. This reduces the expenses for alterations and the overall costs to a minimum. Depending on the connection module type, up to 12 incoming and 12 outgoing 8-wire cables can be permanently connected together without any significant reduction in the transmission characteristics or limitation of the maximum link lengths.

Performance Characteristics:

  • Connection via LSA Plus terminals on a common PCB
  • Colour coding acc. to EIA/TIA 568A and B
  • Connection of 4-pair shielded/unshielded installation and patch cords from AWG 27-22
  • Pairs can be brought directly up to the terminal without untwisting the pairs
  • Secure shielded contact using screw-on terminals directly on the PCB
  • Variable cable feeds
  • Cable strain relief using commercially available cable ties (VM 8-8 Cat.7A)
  • Tool-free installation of shielding cover made of stainless steel (19″ and on-wall mounted version)
